1987 Honda VF 400 F Specs

motorcycle specs

These are the known mechanical and performance specifications for your 1987 Honda VF 400 F.

Basic Specs

Year1987
MakeHonda
ModelHonda VF 400 F
Cost

Engine

Displacement399.00 ccm (24.35 cubic inches)
Type
DetailsV4, four-stroke
Max RPM12500
Compression11.0:1
Bore/Stroke55.0 x 42.0 mm (2.2 x 1.7 inches)
Valves/Cylinder4
FuelingCarburettor. Four Keihin VD40A, 27mm carburettors
IgnitionDigital; Two units, type Toyo Denso FW82-TRI
Exhaust4 in 2
LubricationWet sump
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchWet plate
Driveline

Performance

Horespower55.00 HP (40.1 kW)
Torque35.00 Nm (3.6 kgf-m or 25.8 ft.lbs)
Top Speed172.0 km/h (106.9 mph)

Fuel Economy & Polution

Fuel Consumption4.50 litres/100 km (22.2 km/l or 52.27 mpg)
Fuel Capacity17.00 litres (4.49 gallons)
Emissions104.4 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Typeround steel tubes
Rake
Trail
Front SuspensionShowa 35mm, with 4-position anti dive and adjustable air charge
Front Travel140 mm (5.5 inches)
Rear SuspensionHonda Pro-link monoshock, with adjustable air charge
Rear Travel110 mm (4.3 inches)
Seat
Seat Height780 mm (30.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,160 mm (45.7 inches)
Total Length2,085 mm (82.1 inches)
Total Width750 mm (29.5 inches)
Ground Clearance140 mm (5.5 inches)
Wheelbase1,415 mm (55.7 inches)
Dry Weight175.0 kg (385.8 pounds)
Wet Weight193.0 kg (425.5 pounds)

Wheels & Brakes

Front Tire/Tyre100/90-16H
Rear Tire/Tyre110/90-18H
Front BrakesSingle disc. inboard ventilated cast iron disk, 2-piston calipers
Front Brake Diameter
Rear BrakesSingle disc. inboard ventilated cast iron disk, 2-piston calipers
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Honda VF 400 F. This Sport touring model is powered by a V4, four-stroke engine with 399.00 ccm (24.35 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Carburettor. Four Keihin VD40A, 27mm carburettors allowing this machine to produce its 55.00 HP (40.1 kW) horsepower and 35.00 Nm (3.6 kgf-m or 25.8 ft.lbs) torque. According to our records engine heat of the Honda VF 400 F is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 100/90-16H and the rear is 110/90-18H . The entire package is supported by the frame, round steel tubes. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. inboard ventilated cast iron disk, 2-piston calipers front brakes and Single disc. inboard ventilated cast iron disk, 2-piston calipers rear brakes. The Honda VF 400 F was launched in 1987, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Removable left hand frame tube is part of the cooling system.
